產品型號：PB11A-11M-SB-SGN-S
PB11A-11M-SB-SGN-S
產品規格：
Switching Voltage min. 100 mVAC/DC , max.
48 VAC /48 VDC
Switching current max. 200 mA
Lifetime Over 10,0000 cycles
Capacity 1.2 W
Contact Resistance < 20 mΩ< 25 mΩ after lifetime
Insulation Resistance > 10\’000 MΩ
Actuating Force 1.2 ± 0.6 N
Actuating Travel 1.3 ± 0.5 mm
應用領域：
Audio/video, information and communication technology equipment - Part
1: Safety requirements
